Product Description

The Jasic MIG 250 Pulse MIG welder is a great value for money single phase MIG/MAG/MMA power source. The unit is feature rich and has synergic programmes pre loaded with optimal parameters for inexperienced welders but with a provision of fine tuning for the experienced welder. The pulsed MIG mode allows for high quality welds with a spatter free finish.

Please call us for a great deal ! 02392 295612

Features

  • Compact modern design, advanced IGBT technology
  • Four welding modes, MMA, lift TIG, MIG/MAG and DC
  • Accurate pre-set current/voltage
  • 2T/4T latching
  • Digital display shows set and precise values prior to welding
  • Gas selection and wire selection
  • Welding parameters can be automatically selected
  • Four roll drive unit
  • Easy arc starting with low spatter in DC mode
  • Auto compensation for mains voltage fluctuations
  • Electronic inductance adjustment
  • High duty cycle
  • Cooling chamber keeps dirt away from electronics
  • Low weight
  • Quiet running

Supplied with MIG torch, gas regulator, work return lead and clamp.

5 Year warranty

Technical Data

Amps Range 40-250
Efficiency (%) 82
Amps @ 40% Duty Cycle 250A
MMA Amps @ 40% Duty Cycle 220A
Input power (kVA) 9.13
No load voltage 75
Dimensions (LxWxH mm)  895 x 554 x 760
Voltage adjustment range (V) 13.5 - 36
Welding Wire spool sizes 5 + 15kg
Approx Weight 49.7kg

OPERATORS MANUAL

Specifications

Input power voltage (V)
230V
Brand
JASIC
Product Code
JM250-P

Delivery & Returns

UK Delivery

Postage and packing to mainland UK is free on all orders over £60.00 (exc VAT. All orders up to £60.00 (exc VAT) are £5.75 plus VAT.

Click and collect is now available for PO and SO postcodes.

Outside of the UK

For delivery to an address outside the UK please call us on 023 92 295612 or email us at sales@migtigarc.co.uk and we will advise.

Jasic MIG 250 Pulse MIG Welder

Product Code JM250-P

Key Features

Synergic MIG

MIG + MMA welding

5 Year warranty *

Beautiful weld finish

Auto mains input compensation
