TIG Welders
TIG Welders are ideal for welding metals usually considered difficult to weld. TIG is also renowned for its usefulness for welding thin materials down to a thickness of 0.4mm in materials such as stainless steel, nickel alloys and titanium. TIG DC is usually used when welding ferrous metals such as mild steel, TIG AC is normally used welding non-ferrous metals such as aluminium.
When choosing a TIG Welder
- What power supply voltage do you have ?
- What material are you going to weld ?
- What material thickness are you going to weld up to ?
- what functions would you like eg: pulse etc...
- What is your budget ?
TIG machines are normally equipped with some of the following features:
HF Ignition is a high frequency spark (electronic impulse) created to initiate current flow between the electrode and the work piece. In DC mode the HF spark is removed once the welding current is established, but in AC mode the HF remains in place to stabilise the arc.
Lift Arc is a facility which allows for starting the arc without high frequency (HF). This is particularly useful in areas where HF could interfere with computer and tele-communications.
Pre-gas, on a variable timer, allows for purging the torch and weld start area prior to establishing the arc. This ensures the weld starts in an inert atmosphere.
Up-slope allows you to commence welding with a gradual (timed) increase in the welding current up to the selected main current level.
Down-slope is a gradual (timed) reduction in the welding current down to a final, normally pre-set level, thus eliminating crater cracks or high temperature gas holes on completion of the weld.
Post-gas, again on a variable timer, ensures gas coverage to protect the completed weld area from atmospheric contamination.
Trigger Latch (sometimes called 4T) save keeping the trigger pressed during the welding cycle, especially useful during long weld runs. An initial press and release of the trigger starts the weld and a subsequent press and release stops the weld.
AC Balance (only on some AC DC TIGs) gives you the ability to offset the AC, in order to control the weld penetration, width and cleanliness.
Remote Control, normally achieved with a foot pedal, gives variable control of the welding current (and therefore arc). The pedal can also be used as the trigger switch.
Pulse simply pulses the frequency of the weld current to reduce heat allowing for easier welding of thin materials.
Discover our wide range of TIG welding products for sale. Here at Migtigarc, we have been supplying the welding market with premium brands, great prices and helpful customer service since 1987. If you need any help choosing the products you need, feel free to give us a call on 02392 295 612 or email sales@migtigarc.co.uk and well be happy to help.
We offer free mainland UK delivery on all orders over £60 (exc VAT).
View
£1,190.40 inc. VAT From: £992.00
Key Features
Pulse
Peak current control
MMA
Digital display
VRD
£1,918.80 inc. VAT £1,599.00
Key Features
Chopper technology
230/400V
AC balance control
HF + pulse
5 - 220 amps
£2,262.00 inc. VAT From: £1,885.00
Key Features
Chopper technology
Super smooth weld
HF + Pulse
230/400V
5 - 270 amps
£1,006.80 inc. VAT From: £839.00
Key Features
HF Square-wave AC
Dual voltage
MMA capability
Pulse
Portable
£1,952.40 inc. VAT From: £1,627.00
£2,689.20 inc. VAT From: £2,241.00
Key Features
Chopper technology
Variable AC frq
230/400V
HF + pulse
5 - 330 amps
£1,018.80 inc. VAT From: £849.00
Key Features
Popular model
Square-wave
AC/DC
Variable torch
Lightweight
£1,245.60 inc. VAT £1,038.00
Key Features
Chopper technology
Robust construction
Dual voltage
HF start
5 - 200 amps
£1,479.60 inc. VAT From: £1,233.00
Key Features
Square wave
Balance control
MMA
Pulse
400v
£2,965.20 inc. VAT From: £2,471.00
Key Features
Water cooled
Perfect arc starts
Pulse
Balance control
Variable AC frequency
£1,504.80 inc. VAT From: £1,254.00
Key Features
Chopper technology
Smooth stable arc
HF start
Cable compensator
5 - 250 amps
£3,088.80 inc. VAT From: £2,574.00
Key Features
Water cooled
Square wave
Balance control
Variable AC frequency
Low power consumption
£2,293.20 inc. VAT From: £1,911.00
Key Features
Pulse
Multi wave functions AC
VRD function
Memory storage
MMA
£3,793.20 inc. VAT From: £3,161.00
Key Features
Water cooled
Pulse
Low power consumption
Balance control
Perfect arc starts
£1,764.00 inc. VAT From: £1,470.00
Key Features
Dual voltage
Robust DC MMA/TIG
Generator friendly
HF start
10 - 300 amps
£1,198.80 inc. VAT £999.00
Key Features
MIG/TIG/MMA
Dual voltage
Welds down to 0.9mm material
Rapid synergic set up
3 year warranty
£2,002.09 inc. VAT From: £1,668.41
Key Features
HF start on AC and DC TIG
4 in 1 multi- process
Memory function
Rapid synergic set up
Takes 15kg spools
£2,238.00 inc. VAT £1,865.00
Key Features
Multi-wave AC
Pulse
Variable AC frequency
MMA capability
£670.80 inc. VAT From: £559.00
Key Features
110/230V
HF ignition
TIG + MMA
5 Year warranty
Up to 180 amps
£886.80 inc. VAT From: £739.00
Key Features
5 Year warranty
110/230V
TIG/MMA
HF ignition
5 - 200A pulse frq
£1,558.80 inc. VAT From: £1,299.00
Key Features
Multi AC wave form
Full digital control
HF + pulse
5 Year warranty
Up to 320 amps
£3,526.32 inc. VAT From: £2,938.60
Key Features
High speed pulse
Digital display
Memory storage
MMA
Multi wave functions in AC
£3,118.80 inc. VAT £2,599.00
Key Features
Multi-wave AC
Pulse
Variable AC frequency
MMA capability
Digital control
TIG Welders are ideal for welding metals usually considered difficult to weld. TIG is also renowned for its usefulness for welding thin materials down to a thickness of 0.4mm in materials such as stainless steel, nickel alloys and titanium. TIG DC is usually used when welding ferrous metals such as mild steel, TIG AC is normally used welding non-ferrous metals such as aluminium.
When choosing a TIG Welder
- What power supply voltage do you have ?
- What material are you going to weld ?
- What material thickness are you going to weld up to ?
- what functions would you like eg: pulse etc...
- What is your budget ?
TIG machines are normally equipped with some of the following features:
HF Ignition is a high frequency spark (electronic impulse) created to initiate current flow between the electrode and the work piece. In DC mode the HF spark is removed once the welding current is established, but in AC mode the HF remains in place to stabilise the arc.
Lift Arc is a facility which allows for starting the arc without high frequency (HF). This is particularly useful in areas where HF could interfere with computer and tele-communications.
Pre-gas, on a variable timer, allows for purging the torch and weld start area prior to establishing the arc. This ensures the weld starts in an inert atmosphere.
Up-slope allows you to commence welding with a gradual (timed) increase in the welding current up to the selected main current level.
Down-slope is a gradual (timed) reduction in the welding current down to a final, normally pre-set level, thus eliminating crater cracks or high temperature gas holes on completion of the weld.
Post-gas, again on a variable timer, ensures gas coverage to protect the completed weld area from atmospheric contamination.
Trigger Latch (sometimes called 4T) save keeping the trigger pressed during the welding cycle, especially useful during long weld runs. An initial press and release of the trigger starts the weld and a subsequent press and release stops the weld.
AC Balance (only on some AC DC TIGs) gives you the ability to offset the AC, in order to control the weld penetration, width and cleanliness.
Remote Control, normally achieved with a foot pedal, gives variable control of the welding current (and therefore arc). The pedal can also be used as the trigger switch.
Pulse simply pulses the frequency of the weld current to reduce heat allowing for easier welding of thin materials.
Discover our wide range of TIG welding products for sale. Here at Migtigarc, we have been supplying the welding market with premium brands, great prices and helpful customer service since 1987. If you need any help choosing the products you need, feel free to give us a call on 02392 295 612 or email sales@migtigarc.co.uk and well be happy to help.
We offer free mainland UK delivery on all orders over £60 (exc VAT).
